CPU

ARM Contex-A53 1.5GHz

Memory

2GB   +16GB

Communication   transmission

Eurasian   Network

FDD-LTE:B1/B3/B5/B7/B8/B20/B26/B28

TDD-LTE:B38/B39/B40/B41

WCDMA:B1/B2/B5/B8

GSM/EDGE/GPRS: 850/900/1800/1900

latin   american network

(optional)

FDD-LTE:B2/B4/B5/B7/B12/B13/B14/B17/B28

TDD-LTE:B38/B39/B40/B41

WCDMA : B2/B4/B5/B8

GSM/EDGE/GPRS : 850/900/1800/1900

Communication   Interface

Dual-band Wi-Fi, Bluetooth 4.1+ BR/EDR   + BLE, GPS

product   specifications

Display

5.0 16:9 full lamination assembly HD 720x1280 dots G+F

printer

2- inch high-speed thermal printer, speed 100mm/   second,

Paper roll width 58mm, paper roll   diameter 40mm

Supports glue-free thermal label   printing

Support barcode proofing and picture   proofing

PSAM

1 x standard PSAM card holder; supports 1.8V/3.3V/5.0V   ,

Comply with ISO7816   specification

SIM

1 x SIM : 1×micro SIM card

Type-C

1 x Type-C ,   support OTG

Camera

Front camera FF ,   200 pixels

Rear camera FF , 5   million pixels, independent algorithm support

Supports taking pictures and 1D/2D   quick code scanning ,   supports   full code

NFC reader

(optional)

Standard   Android interface NFC   version:

Support   Type A ,   TypeB ,   Mifare ,   Felica ,   ID card

Support   13.56MHZ, IISO/ICE14443 , ISO15693   standards

Support   card reading, card simulation, point-to-point

     scanning   read head

(optional)

Supported   QR code systems: QR   Code , Micro   QR , Data   Matrix , PDF417   , Micro   PDF417 , Aztec

Supported   one-dimensional code systems: Code   128 , EAN-13   , EAN-8   , UPC-E   , UPC-A   , ISBN   , ISSN   , Code11   ,

ITF-25   ( Interleaved   2 0f 5 ), Code39   , Code93   , Code32   , Codabar

Matrix   2 of 5 , Industrial   25 , IATA   25 , MSI   Plessey

trumpet

1 x 2030 runway type speaker , rated   power 1W ,

Loudness above

physical   buttons

1 x power button

Function   keys

2 x scan / custom function keys (orange)

Operating   temperature

0℃～50℃

storage   temperature

-20℃～70℃

Relative   humidity

5% ~ 95% (non-condensing)

Battery

Polymer battery , 7.6V/2500mAh   (equivalent to 4.2V/5000mAh   )

power   supply

DC5V, 2.5A

Product   Size

178*80*56mm

Libya

AI-   Kamel

     Austria

Certapos

Saudi   Arabia

Bluetooth   Thermal

Barbados

LightBlue

…

     other

Uniapp

Support demo

Flutter

Support demo

Product   qualification

Product safety certification

CCC   is   preparing

Product safety certification

CTA   in   preparation

Product safety certification

SRRC   is   preparing

Battery

Safety   certification in preparation
